专业级DLP 3D打印机Shape 1系列

Print speed up to 50mm/h*

Rayshape Shape 1 series 3D printers use high-speed DLP technology with instant exposure of the entire layer, increasing the printing speed up to more than 10 times compared to SLA technology.

Long life and maintenance-free DLP light machine

Shape 1 series of products use high-performance DLP optical machine, built-in from the United States Texas Instruments DMD chip and imported high-quality LED light source, stable and reliable, with a service life of up to 30,000 hours. Compared with LCD 3D printing technology, the core optical system of Rayshape Shape 1 series has a long life span and is maintenance-free, avoiding downtime and maintenance.

From the appearance of prototypes, to higher-order application scenarios

The Shape 1 series is equipped with Rayshape's high-performance photosensitive resin system, which features high mechanical strength, low deformation, and stable strength and dimensional performance, allowing you to move beyond cosmetic verification to the printing of functional components, machining of fixtures, and production of spare parts, empowering you throughout the product lifecycle.

Proven Quality

Rayshape Shape 1 series 3D printers have been proven by many industrial customers and have withstood the test of the market with very reliable and durable features.
High Reliability Of DLP Technology

Rayshape Shape 1 series DLP optical machines with Texas Instruments DMD chips have a lifetime of up to 30,000 hours.
Excellent Ease-of-use

The ease of use of the Shape 1 series is reflected in the calibration-free molding platform and resin grooves, the well-thought-out anti-distortion design, and the intelligent software functions.

Highly Accurate Output To Precisely Reproduce Design Intent

High dimensional accuracy and high detail resolution ensure that every print moves your business forward smoothly

高精度输出，精确还原设计意图

Whatever the use, you will want a 3D printer that can accurately reproduce your design intent and even faithfully output flaws in your design.

In this way, you can smoothly move your work in the right direction. And that's exactly how 3D printing technology should behave.

The Shape1 series is just that. With industry-leading accuracy advantages, tight dimensional tolerances, and the ability to output intricate, fine detail, the Shape1 series is a high-performance desktop 3D printer that truly has the limits of powerful applications.

Efficiency Reinvents Value

Rayshape's innovative combination of HSP high-speed peel-off technology and DLP digital surface projection technology allows the Shape 1 Series to achieve print speeds of up to 50mm height per hour*, meaning that multiple 10cm tall parts can be printed simultaneously in a single pass in as little as 2 hours.
（*Specific speed, depending on material type and accuracy settings）

Bigger Size, More Possibilities

Meet the needs of diverse parts throughout the product lifecycle, from design and development to assembly and quality control

更大尺寸，更多可能

Larger molding sizes mean greater application flexibility. In addition to printing large parts, you can also print multiple small parts in a single run for greater efficiency.

From product appearance prototypes, to functional prototypes, to tooling fixtures, parts vary in size and you need a larger molding size to meet the needs of different departments and applications across the product lifecycle.

Easy To Use Software, Quick To Get Started

Intelligent model analysis technology for a highly automated user experience

Auto-Rotation And Typesetting

With ShapeWare pre-processing software, you can process scanned models more quickly and rotate them to the right print angle with one click.
Automatic Addition Of Support Structures

ShapeWare's highly accurate and intelligent automatic support features can greatly shorten your file preparation process and reduce the difficulty of getting started with the software.

Easy To Use, Safe And Secure

Years of technology accumulation to create a perfect product design

Print Bin Thermostat Control

The print bin has a built-in air circulation heating device to ensure that the printing process is not affected by the ambient temperature, so you can get stable and consistent print quality and print success rate all year round.
Print Bin Air Purification

The print bin has a built-in HEPA air filter, which keeps the air circulating and filtering during the printing process, maintaining the air quality of the office environment for a long time and reducing the impact of photosensitive resin on the environment.
Safety Door Design

To reduce the risk of use, Shape 1 series 3D printers, if the bin door is opened during the printing process, the printing process will be immediately suspended.

Specifications
Consumables
Hardware
Software
Size Weight

Model	Shape 1	Shape 1 HD
Forming size	192 × 108 × 290 mm	144 × 81 × 190 mm
Pixel size	100 μm	75 μm
Technology Type	Low peel DLP light curing technology
Technology Type	0.025 - 0.3 mm
Forming speed	Up to 80 mm / h Print speed is related to the type of consumables used and print settings

Model	Shape 1	Shape 1 HD
Available supplies	Standard, high resolution, toughness, rigidity, high temperature resistance, red wax, dental mold, orthodontic, guide plate, denture gingiva, memory model, aesthetic wax type, etc.
Consumables capacity	1kg

Model	Shape 1	Shape 1 HD
Light source	UV LED light source, Texas Instruments DMD chip
Light source band	405nm
Resolution	1920 x 1080 PX
Bin door control	Automatic pause in printing when the bin door is opened during printing (this function can be turned on or off)
Molding environment	Automatic thermostatic control of the molding bin
Air Filtration	Built-in air filtration device in the molding bin
Touch Screen	7" color capacitive screen
Transmission method	USB flash drive, wireless network, Ethernet cable
Input	100-240 VAC，50/60 Hz
Overall power	450 W

Model	Shape 1	Shape 1 HD
Operating System	Windows 7/8/10
File formats	.STL, .OBJ, .SHAPE
Slicing Software	ShapeWare
High-level functions	Support editing, automatic repair, model cutting, shell extraction, hole punching, labeling
Wireless Printing	Supports one-click sending of print jobs to devices within the LAN
Cluster Management	Manage print jobs for multiple devices on a LAN with remote control
Software Language	Chinese, English

Model	Shape 1	Shape 1 HD
Device Size	420 × 462 × 815 mm	420 × 455 × 655 mm
Bin door open	420 × 886 × 815 mm	420 × 879 × 655 mm
Net weight	33 kg	29 kg
Packing size	700 × 700 × 1150 mm	700 × 700 × 1050 mm
Packing weight	54kg	50kg
